New release: dynmhs-0.2.0.
Dynamic Multi-Homing Setup (DynMHS) dynamically sets up IP routing rules, to allow for using multiple network connections simultaneously. That is, for each relevant network interface, a separate routing table is created and maintained. For each source address of a network interface managed by DynMHS, routing rules are maintained to point to the corresponding routing table. Software binding to a specific interface address can then use a specific network. In addition, multi-homing-capable network protocols like the Multi-Path TCP (MPTCP) or the Stream Control Transmission Protocol (SCTP) can take advantage of multi-homing for redundancy and load balancing.
A Linux PC is connected to two NAT networks, configuration is dynamic via IPv4 DHCP and IPv6 auto-configuration:
Network settings for Netplan (in /etc/netplan/testpc.yaml):
network:
version: 2
ethernets:
enp0s8:
accept-ra: true
dhcp4: true
dhcp4-overrides:
route-metric: 200
enp0s9:
accept-ra: true
dhcp4: true
dhcp4-overrides:
route-metric: 300
IPv4 routes:
user@testpc:~$ ip -4 route show default via 172.30.255.1 dev enp0s8 proto dhcp src 172.30.255.4 metric 200 default via 192.168.255.1 dev enp0s9 proto dhcp src 192.168.255.4 metric 300 172.30.255.0/24 dev enp0s8 proto kernel scope link src 172.30.255.4 metric 200 172.30.255.1 dev enp0s8 proto dhcp scope link src 172.30.255.4 metric 200 192.168.255.0/24 dev enp0s9 proto kernel scope link src 192.168.255.4 metric 300 192.168.255.1 dev enp0s9 proto dhcp scope link src 192.168.255.4 metric 300
IPv6 routes:
user@testpc:~$ ip -6 route show fc88:1::/64 dev hostonly101 proto kernel metric 256 linkdown pref medium fdc9:dc25:8e35::/64 dev enp0s9 proto ra metric 300 pref medium fdff:b44d:605c::/64 dev enp0s8 proto ra metric 200 pref medium fe80::/64 dev enp0s8 proto kernel metric 256 pref medium fe80::/64 dev enp0s9 proto kernel metric 256 pref medium default via fe80::5054:ff:fe12:3500 dev enp0s8 proto ra metric 200 expires 788sec pref medium default via fe80::5054:ff:fe12:3500 dev enp0s9 proto ra metric 300 expires 772sec pref medium
Note the two default routes with their different metrics (200, 300).
The expectation is that, according to the chosen source address, a packet is routed via the corresponding interface (enp0s8 or enp0s9). This can be tested by using HiPerConTracer 2.0, running HiPerConTracer Ping to Google Public DNS servers (8.8.8.8, 2001:4860:4860::8888) from all four source addresses:
user@testpc:~$ sudo hipercontracer -P \ -S 172.30.255.4 -S 192.168.255.4 \ -S fdff:b44d:605c:0:a00:27ff:fedb:ad69 -S fdc9:dc25:8e35:0:a00:27ff:feaa:bc91 \ -D 8.8.8.8 -D 2001:4860:4860::8888
Connectivity is always over the primary interface, i.e. 172.30.255.4 and fdff:b44d:605c:0:a00:27ff:fedb:ad69. The reason is: This default route has the lowest metric! Also, simply using the same metric for both routes does not fix the issue. Then, just the first default route in the routing table would get used.
To get the setup working as expected, it is necessary to configure separate routing tables for each network, and routing rules to select a routing table according to the source IP address. For example:
Rules:
user@testpc:~$ ip rule show 0: from all lookup local 2000: from 172.30.255.4 lookup 2000 3000: from 192.168.255.4 lookup 3000 32766: from all lookup main 32767: from all lookup default user@testpc:~$ ip -6 rule show 0: from all lookup local 2000: from fdff:b44d:605c:0:a00:27ff:fedb:ad69 lookup 2000 3000: from fdc9:dc25:8e35:0:a00:27ff:feaa:bc91 lookup 3000 32766: from all lookup main
Tables:
user@testpc:~$ ip route show table 2000 default via 172.30.255.1 dev enp0s8 proto dhcp src 172.30.255.4 metric 200 172.30.255.0/24 dev enp0s8 proto kernel scope link src 172.30.255.4 metric 200 172.30.255.1 dev enp0s8 proto dhcp scope link src 172.30.255.4 metric 200 user@testpc:~$ ip -6 route show table 2000 fdff:b44d:605c::/64 dev enp0s8 proto ra metric 200 pref medium fe80::/64 dev enp0s8 proto kernel metric 256 pref medium default via fe80::5054:ff:fe12:3500 dev enp0s8 proto ra metric 200 pref medium user@testpc:~$ ip route show table 3000 default via 192.168.255.1 dev enp0s9 proto dhcp src 192.168.255.4 metric 300 192.168.255.0/24 dev enp0s9 proto kernel scope link src 192.168.255.4 metric 300 192.168.255.1 dev enp0s9 proto dhcp scope link src 192.168.255.4 metric 300 user@testpc:~$ ip -6 route show table 3000 fdc9:dc25:8e35::/64 dev enp0s9 proto ra metric 300 pref medium fe80::/64 dev enp0s9 proto kernel metric 256 pref medium default via fe80::5054:ff:fe12:3500 dev enp0s9 proto ra metric 300 pref medium
It would be possible to configure static rules/tables in Netplan. But DHCP and IPv6 auto-configuration use dynamic addresses. So, they may change!
Dynamic Multi-Homing Setup (DynMHS) is the solution for dynamically creating, adapting, and destroying routing tables and rules. DynMHS monitors the system's network configuration for changes, and applies the necessary settings for additional routing tables and the corresponding routing rules. This works for IPv4 and IPv6, including multiple addresses as well as additional routes over the monitored interfaces.
sudo dynmhs --interface enp0s8:2000 --interface enp0s9:3000 --loglevel 2
Configuration in /etc/dynmhs/dynmhs.conf:
# ====== Logging Verbosity ================================================== # 0=trace, 1=debug, 2=info, 3=warning, 4=error, 5=fatal LOGLEVEL=2 # ====== Options ============================================================ NETWORK1="enp0s8:2000" NETWORK2="enp0s9:3000" NETWORK3="" NETWORK4="" NETWORK5=""
These settings map interface enp0s8 to routing table #2000, and interface enp0s9 to routing table #3000. DynMHS will maintain the tables, and the corresponding rules.
To enable and start the DynMHS service:
sudo systemctl daemon-reload sudo systemctl enable dynmhs sudo systemctl start dynmhs
To observe the logs of the DynMHS service:
sudo journalctl -f -u dynmhs
Another test with HiPerConTracer 2.0, running HiPerConTracer Ping to Google Public DNS servers (8.8.8.8, 2001:4860:4860::8888) from all four source addresses:
user@testpc:~$ sudo hipercontracer -P \ -S 172.30.255.4 -S 192.168.255.4 \ -S fdff:b44d:605c:0:a00:27ff:fedb:ad69 -S fdc9:dc25:8e35:0:a00:27ff:feaa:bc91 \ -D 8.8.8.8 -D 2001:4860:4860::8888 ... 2025-02-28 13:59:50.422: Ping ICMP 192.168.255.4 8.8.8.8 Success s: 27µs q: 4µs r: 54µs A:8.892ms S:8.808ms H:--- 2025-02-28 13:59:50.422: Ping ICMP fdff:b44d:605c:0:a00:27ff:fedb:ad69 2001:4860:4860::8888 Success s: 51µs q: 6µs r:246µs A:8.634ms S:8.331ms H:--- 2025-02-28 13:59:50.422: Ping ICMP 172.30.255.4 8.8.8.8 Success s: 38µs q: 4µs r:125µs A:9.272ms S:9.105ms H:--- 2025-02-28 13:59:50.422: Ping ICMP fdc9:dc25:8e35:0:a00:27ff:feaa:bc91 2001:4860:4860::8888 Success s: 29µs q: 2µs r:162µs A:8.651ms S:8.458ms H:--- ...
Now, there is connectivity over both interfaces, as intended!
Please use the issue tracker at https://github.com/simula/dynmhs/issues to report bugs and issues!
For ready-to-install Ubuntu Linux packages of Dynamic Multi-Homing Setup (DynMHS), see Launchpad PPA for Thomas Dreibholz!
sudo apt-add-repository -sy ppa:dreibh/ppa sudo apt-get update sudo apt-get install dynmhs
For ready-to-install Fedora Linux packages of Dynamic Multi-Homing Setup (DynMHS), see COPR PPA for Thomas Dreibholz!
sudo dnf copr enable -y dreibh/ppa sudo dnf install dynmhs
Dynamic Multi-Homing Setup (DynMHS) is released under the GNU General Public Licence (GPL).
Please use the issue tracker at https://github.com/simula/dynmhs/issues to report bugs and issues!
The Git repository of the Dynamic Multi-Homing Setup (DynMHS) sources can be found at https://github.com/simula/dynmhs:
git clone https://github.com/simula/dynmhs cd dynmhs cmake . make
